Before you Start Laser Cutting and Engraving Wood

Choosing the Power of the CNC Engraving Laser - 6W, 15W, or 45W?

When considering a blue laser for cutting and engraving on wood, you often need to decide about its power. The 6W laser, such as the PLH3D-XT-50, offers a balance between speed and precision. This laser is capable of engraving images in Ultra HD definition, while also being able to cut at the maximum speed of popular CNC machines.

However, such a level of precision requires a machine that is not only very accurate but also has rigidity suitable for operating speeds that guarantee high repeatability of the trace after the head changes its direction of movement. Also, less powerful CNC laser needs more time to complete engraving, because high-resolution images are made of a larger number of thinner lines, and enlarging the spot size (pixel) means a slower movement of the head.

The PLH3D-XF+ 6W laser head is less precise, but in exchange enables faster operation thanks to larger pixel size. For example, it can quickly produce a 30x30 cm image built from half-millimeter pixels. The effective resolution is 600x600 pixels (360 thousand points in total) while working with 0.1 mm pixel would result in a 9kk pixel image (3000x3000). This is a massive difference, especially in terms of engraving time, while the larger pixel size (and lower resolution) will be noticeable only from a distance closer than 1-2 meters.

The 15 W laser head is a three-laser-diodes laser head that uses precision-grade lenses and has the highest optical power density among its counterparts. PLH3D-15W has the same beam spot size as the PLH3D-6W-XF+ with the uSpot Lens Upgrade, but three times as high power density, making it ideal for fast wood cutting.

The PLH3D-XT8 has an unmatched 45W of optical power, making cutting thick wood (up to 20mm) a simple task. At the same time, this laser is capable of engraving images with a high resolution. Thanks to its superior focus depth, it can handle surface irregularities without constant adjustments. The XT8 is an invaluable tool for laser cutting wood and wood-based materials.

Discover Opt Lasers' Exceptional Wood Cutting and Engraving Lasers

Properties of the Material

Cutting and engraving wood using a CNC laser depends on the type of wood, its hardness, as well as other parameters like humidity, or texture. Materials that are easiest to cut with a laser are balsa and aviation plywood. Plywood is made of two layers of slightly harder wood, and a filler - usually balsa. Laser cutting these materials is least problematic, and the process is highly repeatable, since the wood has no knags, and has a foam-like, homogenous structure. When selecting material suitable for laser cutting or engraving, you should check its uniformity. Some variants of balsa are cheaper but may contain splinters of harder wood that are more difficult to cut with a CNC laser. Similar guidelines apply to aviation plywood.

Other types of material are solid wood and hard plywood, for example, used in the construction of window frames. The hardness of the wood and, in the case of plywood, adhesives make such materials less than perfect for cutting with diode lasers. When processing with a laser wood cutter, a carbon-like deposit is created that is black and brittle. Cutting such material too slowly causes the wood to be obscured by this deposit, slowing down the cutting even more, and the wood near the laser's operating area becomes hot and dark. Therefore, it is essential to cut the hard material at high speeds, removing only thin layers. This makes it easy to remove small amounts of cut wood and avoids overheating, darkening, and creating unwanted deposits. You can also use our High Pressure Air-Assist Nozzle to reduce the burning and speed up the wood cutting and engraving process by up to 6.5 times the normal speed.


Selection of the Material and Surface Preparation

Results of engraving heavily depend on wood type. Several parameters need to be taken into account.

Growth Rings and Surface Uniformity. Typically, for best engraving results you need a material of homogenous color. When engraving in shades of gray, remember that darker surface absorbs more laser energy (at the same time it lowers the contrast of the image). All rings, being darker, absorb more light, therefore they get hotter, even at a reduced output power of the laser. The resulting image will be darker on such spots, which means that the engraved image will have unwanted color variations. Rings will stay visible, like an old wallpaper image covered with a low-opacity paint.

Wood-based Materials. MDF boards have surfaces that offer a good rendition of the shades of gray. Such materials lack the charm of natural wood, they don't have growth rings that add unique features to engraved images, but in return, they offer a reliable and highly consistent rendering of the tones. Unfortunately, typical MDF boards are brown or dark brown so images engraved on them won't have high contrasts or bright colors. Also remember, that engraving on fibreboards and MDF involves the formation of poisonous fumes.

The Hardness of the Wood. Usually, engraving hardwood doesn't affect its surface in a significant manner. On the other hand, softwood - especially on darker areas of an engraved image that will be treated with a more powerful beam - will be burned to a significant depth of the material. The burn effect will be particularly visible on aviation plywood and balsa. Additionally, dark areas will be covered with a brittle, smudging deposit that can very easily soil processed surface.

Surface Preparation. It is well worth the effort to finish the wood surface (e.g. with sandpaper) to make it flat, ensuring the constant distance between the laser head and processed material. This is one of the fundamental requirements determining the quality of resulting shades of gray. Uneven surface not only will cause local variations of the focus of the beam and, in turn, the density of energy used to burn in the image, but also induce the changes in the size of the spot of light, which translates to resulting pixel size. This means that you cannot obtain uniform, repeatable shades of gray on an uneven material.

Wood Cutting Laser - Processing Technique

When laser cutting wood and wood-based materials, use the highest available power of the laser engraver, and by varying the speed of the movement you can control the outcome, for example, the intensity of the burn at the cut edge, or even burning through the processed layer. To achieve a clean edge of the cut, you should work in layers, i.e. after the first laser cutting cycle, the head should be lowered (in Z-axis) and start another cycle. These operations should be performed repeatedly, depending on the thickness of the material. This way, we can ensure that the laser beam is focused on the layer that's being cut and not the top surface.

Laser Cutting of Wood

While it might seem that a smaller amount of passes will ensure the shortest wood processing time, it is typically advantageous to cut wood with a higher amount of passes at a higher instantaneous speed instead. The total time required to process a particular material is comparable, however cutting material in more passes results in less scorched and more uniform cutting edges. Utilization of various wood cutting techniques allows you to cut hard water-resistant CDX plywood. Despite having more layers and glue than typical hard plywood you can obtain a highly desirable end effect.

Assembled Laser Cut Wooden Bowl

Cutting wood and other materials producing large amounts of vapors require the quick removal of unwanted gases. Smoke, that consists of microparticles, optically impedes laser beam. If the cutting machine has an insufficient supply of clean air to the laser, some parts of the material may not be cut completely, and, in case of engraving, the resulting image may have inconsistent shades.

You can however provide a sufficient supply of air with the addition of the High Pressure Air-Assist Nozzle. The picture to the right depicts two wooden squares that were cut with a laser. The one on the top was cut with the High Pressure Air-Assist Nozzle, while the bottom one was cut without it.

Laser Cutting of Wood With and Without the High Pressure Air-Assist Nozzle

Laser Engraving in Wood

Speed vs Power

Even small images can consist of a significant number of pixels which takes a long time to laser engrave. That's why users are trying to speed up that process as much as possible. As it turns out, however, the limit comes not from the power of the CNC laser engraver, but the speed of the machine or 3D printer. For slower models a good solution is a technique called diagonal engraving, that is, moving the engraving laser head across the working area in vertical and horizontal direction simultaneously. When both motors of the machine (for X and Y axes) are working together, the net speed of the laser engraving is higher than in one axis alone. You can use this method under the condition that the controller of the machine allows simultaneous movement in both axes.

It's well-worth the effort to take a look at the machine's stability and durability. Despite low power of the laser, engraving small details or cutting out parts that are just a few millimeters across, forces quick direction changes of the laser head. Various CNC machine types can reach various levels of acceleration, however, none can instantly reach the working speed. This means that using lower power of the laser together with lower speed ensures correct rendering of shades even on fine details, and the speed of the head and its rate of acceleration won't affect the outcome.

Laser Engraving on Wood - Speed versus Power

The best-operating conditions can be achieved when at maximum laser power you can move the head at such speed, that engraved line corresponds to black color. This indicates the ability to work at high speed, and at the same time to obtain any shade of gray thanks to modulation of laser power with appropriate G-code. Some materials, however, require two or three engraving passes of the same detail at lowered power. This technique isn't only used to avoid burning the layer close to the spot of the laser, but also to obtain the darkest shades possible. This is especially useful when processing softer wood-based materials, such as balsa or aviation plywood.

Unfortunately, the large variety of materials makes it impossible to create a universal table of processing parameters, like speed or laser power, that would fit given conditions. Therefore, it is essential for the user to perform a series of tests on the selected surface, and set up the machine based on obtained results. This necessity results from the fact that the operating parameters depend on such properties as the temperature of the wood, humidity, storage conditions, density, color, hardness, the density of growth rings, or surface finish.

A very interesting technique is based on focusing laser beam from larger than a usual distance between the head and the surface, for example, 15 cm. Such distance causes the spot of the laser to reach a size of 0.5 mm - 1 mm and, after proper focusing, it will have a square shape. This way we get large pixels that are very useful for fast laser engraving of large images.

Laser Engraved Eagle in a Wood

Fine-tuning a Laser Spot for Laser Engraving in Wood


To achieve the high engraving speed you need to focus a laser beam properly. For that, you can employ one of two basic methods. The first one allows to obtain the smallest possible spot size, and in turn - the highest power density. A very small surface of the spot ensures that the power density - calculated as the power divided by the surface - reaches the highest level, allowing for the fastest working speed. The calibration should begin by engraving several lines at various head distances and along both axes of machine movement. Then select the settings that resulted in thinnest lines of the grid. This method has a disadvantage - the spot won't be square, which results from the properties of the optics of the laser head that renders light of laser diode emitter on the surface of the wood. The rounded shape of the spot is not optimal for engraving pixel-based images.

The software available for CNC machines can be equipped with a feature of selecting spot type, as well as laser engraving method, e.g. from left to right, top to bottom, or diagonally. Our experience shows that the best results can be achieved in diagonal mode. This ensures the most consistent shades. At the edges of the spot, the power density is a bit lower than at the center, so in the diagonal method, the traces left by laser overlap slightly, preventing the formation of distinct edges of image lines, as well as gaps between them.

In another, already mentioned method of focusing the beam, we try to obtain a square laser spot that corresponds to pixel size. To use this technique, first, engrave small squares at various distances of the laser head, and select the settings that resulted in squares with sides of equal thickness. This way the CNC laser will engrave lines of constant thickness, regardless of the direction of the movement (horizontal or vertical).

Laser engraving speed achieved by the latter method will be somewhat slower than for the diagonal technique, however, it results in a different visual effect. Although each of the described methods has its pros and cons, none can be regarded as better or worse than the other. The user should independently test each technique and decide, which suits his needs best.

Baking Soda Treated Wood Engraving

Treating a piece of wood you want to laser engrave can help you to add more depth to the picture.

Baking Soda Treated Wood Engraving

How to Prepare Your Wood

To begin, you need you to decide what type of wood is suitable for your purposes. MDF is generally not recommended because of the high glue content in it. Multiplex wood, for instance birch plywood, on the other hand, is much more suitable for it. To get the best results, it is recommended to prepare a piece of flat, smooth and sanded plywood. You should ideally sand your chunk of plywood before applying baking soda to it.

How to Prepare Your Image

Make sure that the photo is sharp and of a high quality. You can for example use a photo with at least 350 DPI and above a 3000 by 3000 size. You should avoid photos with low quality, otherwise the engraved picture will turn out to be blurry. You can use the grayscale technique.

Baking Soda Treatment

To prepare the mixture for treatment, mix 4 tablespoons of baking soda with 500 ml of water. Stir it well and pour it into a spray bottle. You can then spray it evenly on the wood and let it dry for 24 hours. Once it has properly dried up, you will notice the wood has gained a reflection haze.

You can sand the reflection haze off with an orbital sander and 320 sandpaper to get a flat and smooth surface once again. Then you can use a vacuum cleaner with a brush to vacuum the surface you just sanded. You need to ensure there are no leftover white spots in the piece of wood.

Once you have converted your chosen photo to grayscale and calibrated the working distance, place a piece of wood so that the woodgrain is perpendicular to the direction of laser engraving.

Direction of Wood Engraving

You can then start wood engraving. It is worth noting that because of the baking soda treatment, the laser power you are used to will engrave wood in a way a lower laser power normally would.

It is a good practice to prepare a test material to check first what laser power and speed will produce satisfying results. You can laser just a few millimeters and then see whether you like the shade of the engravement. You can run this test for a few different pictures. You should be looking at the darkest parts of the engraved picture and use it as a reference point to find your ideal parameters.

Once you determine the parameters required to obtain an appropriate colour shade for you, you can start laser engraving your final piece.

When the engraved picture is ready, there is always some leftover ash on the engraved piece. You can blow it off, but it is not necessary. To seal the picture, you should apply several layers of coating on the photo. This should be done in very thin layers and be let to dry thoroughly between subsequent coating applications. Once 3 thin layers of lacquer have been applied, and the piece has dried properly, you can hold the photo with your hands.

The results obtained are shown below:

Laser Cutting in Wood a Picture of Giraffes
Laser Cutting in Wood a Picture of Wildlife

Safe Work with the CNC Laser

Due to serious health risks, processing materials with high power CNC lasers requires following some safety rules:

  • When working, always wear protective goggles, and pay special attention not only to the beam of light that comes out of the head, but also laser rays that are reflected and diffused.
  • It is highly recommended to install additional covers on the machine, which allow easier ventilation, so you can evacuate the smoke outside the room, but also provide extra protection against diffused laser light.
  • It is important to clean the surface of the wood to be processed from any dust particles, for example with a damp cloth. This way during laser engraving you will avoid ignition of small bits of material and wood powder.
  • Since wood is a flammable material that emits large amounts of smoke, your workroom should be well ventilated.
  • Processing plywood, chipboard or MDF can turn adhesives contained in the material into toxic fumes.

We would like to offer our special thanks to Andre Alexander Wijn for laying the groundwork for the "Baking Soda Treated Wood Engraving" section of the article, which included finding out and testing how to laser engrave wood treated with baking soda, providing visual materials as well as writing initial text for this section, which was later worked upon and edited by our Web Development Team. We would also like to thank Paul Deutsch (please visit his facebook group PLDesigns) for the provision of the Speed versus Power photo in the Laser Engraving in Wood section.
