1 x PLH3D-XT-50 Specialized Engraving Laser Head
Specs: 6W Optical Power, Ultra HD 550DPI 45um spot, max wood cutting thickness 3 mm (⅛”)
Best For: Very Detailed Engraving, Thin Materials Cutting
Includes: Laser Head
XT-50 6W Plug&Play Laser Kit for FAB Z-Morph 3D
FAB Z-Morph 3D PLH3D-6W-XT-50 Laser Upgrade Kit
Specs: 6W Optical Power, SD 85 DPI 300um spot, max wood cutting thickness 6 mm (¼”)
Best For: Standard Engraving, Soft Materials Cutting, MultiPass Material Cutting
Includes: Laser Head, Wiring, Safety Glasses, Mounting Screws
Mount: Needs to be 3D-Printed by customer.
Step files below.
SKU:
005147
Manufacturer:
Opt Lasers
Select Accessories
Additional Safety Accessories
|
|
|
$70.00 |
Items included in the kit:
-
-
1 x Laser Safety Glasses
✔ Laser Safety Glasses rated at OD 7+ over the range of 190 to 540 nm.
✔ Reduce the risk of light entering the user’s eyes from backscattered laser light.
-
1 x Signal Cable for PLH3D-6W-ZMorph FAB and VX Laser Head
✔ Signal cable for connection between PLH3D-6W-ZMorph laser head and ZMorph 3D printer.
✔ Transfers control signals from the printer to the laser head.
-
1 x FAB Z-Morph 3D Mount Screws
For: XT-50 6W Plug&Play Laser Kit for FAB Z-Morph 3D
✔ Mounting screws required for assembling the 3D-printed mount for the XT-50 FAB Z-Morph Kit
Downloads
Product description
Kit Components
- PLH3D-XT-50 Laser Head with FAB Z-Morph 3D Customization
- Laser Safety Glasses
- Signal Cable for FAB Z-Morph 3D
- Mounting Screws for 3D-Printed Mount
Features & Benefits of the PLH3D-XT-50 Laser Engraving and Cutting Head
Precision Cutting and Engraving - The PLH3D-XT-50 blue laser head enables high-precision engraving and cutting of various materials, including wood, cardboard, rubber, paper, textiles, leather, plastic, balsa, plywood, and more. Additionally, it allows for marking stainless steel, titanium, and certain types of steel with low heat conductivity. For more details, check the Manuals and Articles section.
Factory-Preset Lens for High Precision - The PLH3D-XT-50 comes with a factory-set lens, optimized for high-resolution engraving and cutting. The laser is pre-focused at 20 mm (from the front surface of the laser to the working plane), ensuring the smallest possible beam spot, which translates to ultra-detailed engraving and clean cuts.
Versatile Input Signals - The built-in driver supports 0-5V analog input and PWM/TTL signals (0-5V, 0-10V, or 0-24V), making it compatible with most CNC controllers.
Built-in Laser Driver for Stability & Performance - The PLH3D-XT-50 integrates the laser driver directly into the head, improving stability, reducing electrical noise, and supporting high-frequency modulation, allowing precise control at high engraving speeds.
Wide Power Supply Compatibility - The integrated high-efficiency DC-DC converter supports 12V-24V input, ensuring low heat generation and built-in overvoltage protection.
No Additional Cooling Required - The laser head features an optimized heatsink design, tested across multiple prototypes to ensure minimal heat buildup. The module's integrated high-performance fan removes smoke from the working area while keeping the laser diode cool.
Ultra-High-Resolution Lens - The PLH3D-XT-50 includes a High-Resolution Triplet Lens, designed to focus laser light into the smallest possible spot for ultra-detailed engraving. The anti-reflection (AR) coating maximizes laser efficiency, improving engraving contrast and cutting performance.
Powerful Integrated Fan – Smoke Removal & Cooling - The laser module is equipped with one of the most powerful fans on the market for its size, delivering 43 m³/h (25 CFM) of airflow, ensuring both efficient cooling and smoke removal, extending the lifespan of the optics and enhancing engraving precision.
Compatible with a Range of Accessories - To enhance user experience and safety, we offer high-quality CNC-machined accessories, including mounting brackets, air assist nozzles, and protective enclosures. Check out our accessories for the PLH3D Series.
OEM Customization Available - We provide OEM customization for 3D printer and CNC machine manufacturers.
Laser Driver Parameters
- Maximum output current capacity: 5 A
- Typical output current: 3-3.5 A
- Input voltage: 12-24V
- Input current: max 2 A
- Integrated microcontroller for temperature measurement and soft start
- Thermal protection system: Automatic shutdown at 45°C
- Soft start feature for diode protection
- Electrostatic discharge (ESD) protection
- Reverse voltage protection
- Overcurrent protection
- Compact design with 90% efficiency
- Supports CW Mode and Input Control Mode
- Compatible with PWM/TTL and analog inputs
- Modulation bandwidth: 0-30 kHz
Advanced Safety Features
The PLH3D-XT-50 includes multiple layers of protection, ensuring safety and longevity:
- Thermal Protection System – Automatic shutdown if ambient temperature exceeds 45°C.
- Overvoltage and Reverse Polarity Protection – Prevents damage from incorrect connections.
- Electrostatic Discharge (ESD) Protection – Ensures long diode lifespan.
- Optically Isolated Inputs – Prevents electrical interference.
Important Safety Information
Caution:
- Laser radiation is hazardous even when reflected or scattered.
- Always use a proper laser safety filter for 430-480 nm wavelengths.
- Never point the laser at people or animals.
- Do not touch the beam; it may cause burns or injuries.
- Avoid staring at the beam spot while cutting or engraving.
- Class 4 laser product – Proper precautions are required.
